IP65-Rated Counter-Rotating Gearbox

Click image to enlarge
IP65-Rated Counter-Rotating Gearboxes offer an efficient and compact solution where Ingress Protection and/or corrosion protection is needed (such as food-related or other applications requiring washdowns).  These units have a T-style design with two output shafts on the same axis and one input shaft at 90° from both outputs.  These IP65-Rated Gearboxes feature stainless steel shafts, shaft seals, and a nickel-plated aluminum housing for corrosion resistance.  The IP65-Rated Counter-Rotating Crown design allows for changes in axis rotation along with minimal backlash.

These Crown Gearboxes were tested at an independent laboratory to obtain the IP65-Rating for both dust and water jet protection.  These corrosion resistant Gearboxes also utilize a premium H1 food-grade grease making them ideal in food-type applications or any drivetrain that may operate in wet or humid environments or be subjected to washdowns.


Dependable and Reliable Power Transmission

IP65-Rated Counter-Rotating Gearboxes are unique in that the two output shafts rotate in opposite directions simultaneously, which creates an ideal counterbalance. A counterbalanced rotating gearbox helps offset vibrations and provides additional stability in mechanical drive systems.  These maintenance-free units transfer power smoothly and quietly, using specially designed, hardened spiral bevel gears for premium performance.

IP65-Rated Counter-Rotating Right Angle Power Transmission Gearboxes feature a fully enclosed nickel-plated housing and shaft seals that ensure its internal gears won’t get out of alignment, won’t jam, and won’t be affected by contaminants. The compact housing provides high strength and can be mounted in any orientation.

See individual product listings to request a quotecontact us, or find your local sales representative.


Advanced Quality IP-Rated Counter Rotating Gears Deliver Smooth and Quiet Power

Crown Gear is a brand of Zero-Max, Inc, offering the most dependable and reliable transfer of power on the market. We offer a wide range of IP65-Rated Counter-Rotating Gearbox shaft styles, as well as specially designed units to handle most applications.  IP65-Rated Counter-Rotating Gearboxes are compact and feature multiple mounting options.  The shaft seals and the fully enclosed design ensure the integrity of the internal gears.

Our premium miter speed reducers feature hardened spiral bevel gears and non-magnetic stainless-steel shafts to transmit quiet, dependable power. Additionally, the nickel plated cast aluminum housing is designed for maximum strength, corrosion resistance, and heat dissipation.  The drives are available with shafts of 3/8”, 1/2”, and 5/8” diameter in both 1:1 and 2:1 ratios. We can also quote several unique types of shaft designs, including:
  • Squared
  • Splined
  • Extended
  • Shortened
  • Stepped


IP65-Rated Counter-Rotating Gearbox Features & Benefits

Zero-Max’s Counter-Rotating Gearboxes have a proven design used in hundreds of applications for over 60 years. They are built from high-quality materials and engineered for long-lasting performance. There are numerous features and benefits associated with our IP65-Rated Counter Rotating gear drives, some of which include:
  • Tested for IP65 Ingress Protection against dirt and water jets
  • Nickel-Plated Housing and Shaft Seals
  • Precision hardened and ground ball bearings for smooth, quiet, long operating life
  • Double sealed bearings that hold lubrication in
  • Non-magnetic and corrosion-resistant stainless-steel shafts require minimal maintenance
  • Option of numerous standard types and sizes, plus special shafts, to fit your application needs
  • Multiple mounting positions simplifies design considerations


IP65-Rated Counter-Rotating Gearbox Applications

Crown Gear 90-degree Counter-Rotating Gear Motors are used throughout dozens of industries in hundreds of applications. Any use that demands reliable transfer of speed or power, you could find a right-angle gearbox bearing the Crown Gear brand. Some of the possible applications for IP65-Rated Right-Angle Gearboxes include:
  • Food Processing Equipment
  • Ovens & Dryers
  • Conveyors
  • Power Transmission Equipment
  • Packaging Equipment
  • Test Equipment
  • Any machine in a humid environment or requiring washdowns

Contact Zero-Max for IP65-Rated Counter-Rotating Gear Solutions

Crown Gear is a brand of Zero-Max, Inc, offering the most dependable and reliable transfer of power on the market. We provide several rotating gearbox designs and both 1:1 and 2:1 ratio options to meet a variety of power transmission needs. Choose from a wide selection of flexible shaft couplings for installing your gearbox.

For more information on Crown Gear IP65-Rated Counter-Rotating Gearboxes, contact us or find your local sales representative.
