Model 928-24 SAE C Mount Overhung Load Adaptors
Part Number: 928-24
Click image to enlarge
Specifications
Click for English
Click for Metric
- Input Standard: SAE C 2 or 4-Bolt Mount
- Input Bore: 1-1/2" with keyway (3/8" x 3/16")
- Input Bore : 38.1mm with keyway (9.53mm x 4.76mm)
- Input Bore Depth: 3.59"
- Input Bore Depth : 91.19 mm
- Output Shaft: 1-3/4" with keyway (7/16" x 7/32")
- Output Shaft : 44.45mm with keyway (11.11mm x 5.56mm)
- Output Shaft Length: 3.00"
- Output Shaft Length : 76.2 mm
- Input Pilot Diameter: 5.000"
- Input Pilot Diameter : 127 mm
- Input Pilot Depth: 0.500"
- Input Pilot Depth : 12.7 mm
- Output Pilot Diameter: 5.000"
- Output Pilot Diameter : 127 mm
- Output Pilot Height: 0.500"
- Output Pilot Height : 12.7 mm
- Max Speed (w/o modification): 1,900 RPM
- Housing Material: Cast Iron
- Shaft Material: 1144 Stressproof Steel
- Bearing Type (std): Tapered Roller Bearings
- Standard Lubrication Method: Grease
- Optional Lubrication Methods: Contact Factory
- Rec. Grease (typical app.): NLGI #2; Lithium Base
- Minimum Grease Capacity: 4.3 oz.
- Maximum Grease Capacity: 8.6 oz.
- Grease Fitting: (1) Zerk Fitting (1/4-18 NPT)
- Unit Weight: 55 lbs
- Unit Weight : 25 kg
- Standard Mounting Orientation: Shaft Horizontal - Consult Factory for other Mounting Orientations
